Product date
Model name:PHILIPS Xitanium 21W 0.5A 42V I 230V 929001410280
12NC:929001410280
Output voltage: 32 to 42 Vdc
Output current: 0.5 A
Output power: 16 to 21 W
Pieces per box: 40
Driver lifetime: 50,000 hours
Control method: Fixed
PRODUCT DATA
Product date
Model name:PHILIPS Xitanium 21W 0.5A 42V I 230V 929001410280
12NC:929001410280
Output voltage: 32 to 42 Vdc
Output current: 0.5 A
Output power: 16 to 21 W
Pieces per box: 40
Driver lifetime: 50,000 hours
Control method: Fixed
Lumiblade OLED Driver-Low Voltage
PHILIPS Xitanium 21W 0.5A 42V I 230V 929001410280
This driver detects the power and voltage needs of the attached OLED and drives the attached OLED Panel accordingly. This one-driver-fits-all-panels approach eases the life of the customers and makes this driver also compatible for future developments.
Benefits
• Driver design based on Philips experience and knowledge of conventional fluorescent and HID technologies
• Various power wattage Drivers that are related to the lumen packages/applications
• Fixed output Drivers
• Independent-version housing design for stand-alone installation
Features
• Small, compact dimensions
• Specific, optimized output current and voltage
• 50,000 hours lifetime
• Fast Time to Market
• Low ripple, low THD
Application
• Public buildings (airports, cinemas, theaters, exhibition halls)
• Retail (supermarkets, shops)
• Office
PHILIPS Product 12NC List
12NC List:
929001410180 Xitanium 15W 0.35A 42V I 230V
929001410280 Xitanium 21W 0.5A 42V I 230V
929001418280 Xitanium 27W 0.6/0.65A 42V I 230V G2
929001418380 Xitanium 32W 0.7/0.75A 42V I 230V G2
929001418580 Xitanium 36W 0.8/0.85A 42V I 230V G2
929001419380 Xitanium 40W 0.9/0.95A 42V I 230V G2
929001418680 Xitanium 44W 1.0A/1.05A 42V I 230V G2
929001418480 Xitanium 34W 0.9/1.05A 32V I 230V G2
929001423380 Xitanium 50W 1.1/1.2A 42V I 230V
929001423480 Xitanium 59W 1.3/1.4A 42V I 230V
929001423580 Xitanium 64W 1.5/1.6A 40V I 230V
